Simple Structure Hot Water Boiler，Double Drum D Type Water Tube Boiler

Brand Name : SWET

Model Number : QXS(SZS)29-1.6-Y,Q-3013

Certification : ISO9001

Place of Origin : Henan China

MOQ : 1 Set/Sets

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement

Supply Ability : 1500 Set/Sets Per Year

Delivery Time : 25-30 work days

Packaging Details : The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements

Leaving Water Temperature : 130(150) ℃

return water temperature : 70(90) ℃

efficiency : 97.8 %

Model : QXS(SZS)29-1.6-Y,Q-3013

Keywords : hot water boiler

Rated thermal power : 29 MW

nominal working pressure : 1.25(1.6) MPa

Color : Customer requirements

Contact Now

Simple Structure Gas Fired Hot Water Boiler For Industrial Production

Product description

1. The company's SZS series of fuel (gas) boiler is a typical D-type arrangement of double-drum longitudinal-type water tube boiler, according to the size of the boiler divided into fast-type and assembly type.

2. With automatic continuous water, the program ignition, proportional pressure control temperature combustion

3. SZS series of fuel (gas) hot water boiler for the classic D-type layout of the boiler.

Product advantages

1. The tail is equipped with flue gas condensate recovery device, can effectively control the exhaust gas temperature, high boiler thermal efficiency

2. Equipped with well-known and efficient brand burner and auxiliary machines, accessories

Customer visit

1. China Petroleum Pipeline Materials and Equipment Corporation.

2. China Petroleum & Chemical Corporation.

3. China Aero Engine Group.

Product parameters

SZS water pipe type full automatic gas-fired hot water energy-saving boiler
Model	Rated thermal power	nominal working pressure	Leaving Water Temperature	return water temperature	efficiency	gas consumption	Overall dimensions of transportation
Unit	MW	MPa	℃	℃	%	Nm³/h	mm
QXS(SZS)58	58	1.25(1.6)(2.5)	130(150)	70(90)	98.3	6196	1536075708318
QXS(SZS)48	48	1.25(1.6)(2.5)	130(150)	70(90)	98.09	5048	1560095007920
QXS(SZS)29	29	1.25(1.6)	130(150)	70(90)	97.8	3150	968568707180
QXS(SZS)14	14	1.0(1.25)(1.6)	115(130)(150)	70(90)	97.02	1558	812033853750
QXS(SZS)10.5	10.5	1.0(1.25)(1.6)	115(130)(150)	70(90)	97	1136	725036823820
QXS(SZS)7	7	0.7(1.0)(1.25)	95(115)(130)	70(90)	96.87	754	677032103775
QXS(SZS)7	7	1.25	115	70(90)	95.76	763	676027803299
QXS(SZS)5.6	5.6	0.7(1.0)(1.25)	95(115)(130)	70(90)	95.57	619.2	645029563620
QXS(SZS)4.2	4.2	0.7(1.0)(1.25)	95(115)(130)	70(90)	95.36	456.7	570031053410
Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output
